Do you need to cut a wide variety of thin materials on a budget?
MultiCam’s 1000 Series CNC Waterjet is the perfect platform for accurate and quality cuts every time!
Basic Information
- 30 HP
- Table sizes: 60″ x 120″ to 80″ x 144″ (152 cm x 305 cm to 203 cm x 365 cm)
- Rapid Traverse: 1,200 IPM (30,5 m / min)
- Repeatability: +/- 0.001″ (0,025 mm)
Standard Features
- MultiCam EZ Control®, Coreo® BMO software
- All-steel, stress- relieved, integral water tank design
- Three-side cutting tank access
- Integrated fork lift tubes
- Dual-side, brushless digital AC servo drives
- Full range of KMT intensifiers
- (Features subject to change without notice)
Options
- Two and three head configurations
- Up to four pure water heads
- CNC Computer Interface Station
- Integrated CNC control air conditioner
- Laser Pointer
- MultiCam Coreo software packages
- Chiller for intensifier
- Closed-loop filtration system
- (Options subject to change without notice)
Specifications
- 25mm linear bearing profile rails
- Z-axis clearance: 4.5” (11,5 cm)
- Z-axis travel: 6” (15 cm)
- Cut speed: 1,000 IPM (25,5 m / min)
- Rapid traverse speed: 1,200 IPM (30,5 m / min)
- Repeatability: +/- 0.001” (0,025 mm)
- Drive system X and Y axis: Linear rack and pinion
- Drive system Z axis: Lead screw
- (Specifications subject to change without notice)
